SMS Fürst Bismarck (1897)

SHIPS LINES AND DETAILS

BOW DETAIL VEIW

STD SIDE BOW SECTION AND DETAILS

BOW DETAILS

BOW FITTINGS DETAILS

FORWARD TURRET AND A SHIPS BOATS DETAIL

LOWER BRIDGE AND SECONDARY GUN DETAIL

UPPER BRIDGE AND FORE FUNNEL DETAILS

FORE FUNNEL AND SHIPS BOATS DETAILS

BASE OF FORE MAST DETAILS

SHIPS BOATS DETAILS

SHIPS BOATS AND BOAT CRANES DETAILS

MID SECTION DETAILS

SHIPS BOATS DETAILS

SHIPS BOATS AND MID SECTION GUN DETAILS

SHIPS BOATS AND MAIN DECK DETAILS

SHIPS BOATS AND AFT LADDERS DETAILS

AFT CONN POSITION DETAILS

AFT CONN DETAILS

AFT SECTION DETAILS DETAILS

AFT TURRET DETAILS

AFT HULL DETAILS

AFT TURRET AND SHIPS BOAT DETAILS

AFT END DETAILS DETAILS

AFT END DETAILS

AFT END DETAILS

---------

Fürst Bismarck

Namesake: Otto von Bismarck

Builder: Kaiserliche Werft, Kiel

Laid down: April 1896
Launched: 25 September 1897
Commissioned: 1 April 1900
Struck: 17 June 1919

Fate: Scrapped in 1919–1920

General characteristics

Class and type: Fürst Bismarck class unique armored cruiser

Displacement:

10,690 t normal
11,461 t full load

Length: 127 m (416 ft 8 in)
Beam: 20.40 m (66 ft 11 in)
Draft: 7.80 m (25 ft 7 in)

Installed power:

3-shaft triple expansion engines
13,500 hp (10,100 kW)

Speed: 18.7 knots (34.6 km/h; 21.5 mph)

Range:

4,560 nmi (8,450 km) at 10 knots (19 km/h; 12 mph)
3,230 nmi (5,980 km) at 12 knots (22 km/h; 14 mph)

Complement:

36 officers
585 men

Armament:

4 × 24 cm (9.4 in) (2 × 2)
12 × 15 cm (5.9 in) (12 × 1)
10 × 8.8 cm (3.5 in) SK L/30 (10 × 1)
6 × 45 cm (18 in) torpedo tubes

Armor:

Belt: 20 cm (7.9 in)
Turrets: 20 cm (7.9 in)
Deck: 3 cm (1.2 in)

SMS Fürst Bismarck (Prince Bismarck) was Germany's first armored cruiser.

She was built for the Kaiserliche Marine just before the turn of the 20th century.

The ship was named after the German statesman Otto von Bismarck.

The design for Fürst Bismarck was an improvement over the previous Victoria Louise-class protected cruiser.

Fürst Bismarck was significantly larger and better armed than her predecessors.

The ship was intended for colonial duties, and served as part of the East Asia Squadron until she was relieved in 1909.

The ship was rebuilt between 1910 and 1914, and after the start of World War I, she was briefly used as a coastal defense ship.

She proved inadequate to this task, and was withdrawn from active duty and served as a training ship for engineers until the end of the war.

Fürst Bismarck was decommissioned in 1919 and sold for scrap.

----------
